304不锈钢电缆固定头

M8 x 1.25

SSCG-M8 -3.8

2-3.8

8

5.5

12/12

20

M10 x 1.5

SSCG-M10 -5.5

2-6.5

10

6.5

14/14

20

M12 x 1.5

SSCG-M12S-6.5

2-6.5

12

7

14/14

20

SSCG-M12 -5.5

3-5.5

12

8

15/18

10

SSCG-M12 -7.8

4.5-8

12

8

15/18

10

M16 x 1.5

SSCG-M16S-5.5

3-5.5

16

9

20/18

10

SSCG-M16S-7.8

4.5-8

16

9

20/18

10

SSCG-M16 -7

4-7

16

9

20/22

10

SSCG-M16 -10

6-10

16

9

20/22

10

M20 x 1.5

SSCG-M20S-8.8

4-8.8

20

9.5

24/24

10

SSCG-M20S-12.5

7-12.5

20

9.5

24/24

10

SSCG-M20 -11

7-11

20

9.5

24/25

10

SSCG-M20 -14

9-14

20

9.5

24/25

10

M25 x 1.5

SSCG-M25S-11

7-11

25

12

30/25

10

SSCG-M25S-14

9-14

25

12

30/25

10

SSCG-M25 -16

12-16

25

12

30/30

10

SSCG-M25 -18

14-18

25

12

30/30

10

M32 x 1.5

SSCG-M32 -22

16-22

32

12

38/40

10

SSCG-M32 -25

18-25

32

12

38/40

10

M40 x 1.5

SSCG-M40 -26

21-26

40

15

46/50

10

SSCG-M40 -31

24-31

40

15

46/50

10

M50 x 1.5

SSCG-M50 -33

25-33

50

15

59/59

10

SSCG-M50 -41

31-41

50

15

59/59

10

M63 x 1.5

SSCG-M63 -45

39-45

63

15

69/69

5

金属电缆防水接头PG型
Brass PG Thread Cable Glands

  螺牙规格
  Thread

编号
Item.No.

电缆范围
Cable Range
Ф(mm)

螺纹外径
Thread O.D.
C1(mm)

螺纹长度
Thread Length
C2(mm)

扳手径
Spanner Size
A&F(mm)

包装
Std.Pkg
(pcs)

PG7

SSCG-PG7S-6.5

2-6.5

12.5

7

14/14

20

SSCG-PG7 -5.5

3-5.5

12.5

8

18/18

10

SSCG-PG7 -7.8

4.5-8

12.5

8

18/18

10

PG9

SSCG-PG9 -5.5

3-5.5

15.2

8

18/18

10

SSCG-PG9 -7.8

4.5-8

15.2

8

18/18

10

PG11

SSCG-PG11-7

4-7

18.6

9

22/22

10

SSCG-PG11-10

6-10

18.6

9

22/22

10

PG13.5

SSCG-PG13.5-8.8

4-8.8

20.4

9.5

24/24

10

SSCG-PG13.5-12.5

7-12.5

20.4

9.5

24/24

10

PG16

SSCG-PG16-11

7-11

22.5

9.5

25/25

10

SSCG-PG16-14

9-14

22.5

9.5

25/25

10

PG21

SSCG-PG21-16

12-16

28.3

12

30/30

10

SSCG-PG21-18

14-18

28.3

12

30/30

10

PG29

SSCG-PG29-22

16-22

37

12

40/40

10

SSCG-PG29-25

18-25

37

12

40/40

10

PG36

SSCG-PG36-26

21-26

47

15

50/50

10

SSCG-PG36-31

24-31

47

15

50/50

10

PG42

SSCG-PG42-33

25-33

54

15

59/59

10

SSCG-PG42-41

31-41

54

15

59/59

10

PG48

SSCG-PG48-45

35-45

59.3

15

69/69

5
